NIBE ground source heat pump

NIBE F1145 PC

Ground source heat pump
  • Product information
  • Advantages

The NIBE F1145 PC is an efficient heat pump with integrated cooling. The heat pump is easy to install even in locations with low ceilings, since the hot water tank is separate and is chosen according to hot water requirements. The NIBE F1145 PC has high a seasonal performance factor and a high temperature range. The NIBE F1145 PC is available in the following output sizes: 5, 6, 8, 10 kW, and is therefore suitable for both apartments and houses. Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected home. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time.

Easy to install

Efficient heat pump and separate water heater for optimum customisation

Efficient

Integrated cooling and high seasonal performance factor

User-friendly

Energy-saving smart technology with user-friendly control

  • Functions
  • Accessories
  • Technical data
  • Document
NIBE undefined
NIBE undefined
NIBE undefined

NIBE Smart Price Adaption

With Smart Price Adaption, the heat pump receives information about the electricity prices for the next 24 hours and then adapts the operation to these. The function is based on information about the hourly prices of the coming day from the electricity exchange NordPool Spot. The prices in combination with expected heating and hot water needs then automatically control the heat pump. This is in order to reduce energy costs and which in the long run contributes to a smaller environmental impact.

Extended functions

With the help of our large range of accessories, the heat pump can offer a variety of functions for heating, cooling, ventilation and solar production. Click on the "Accessories" tab above to read more about the different accessories offered.

NIBE PCM 40

Passive cooling module. Elegant and timeless design High flexibility for best indoor climate Passive cooling and hot water production simultaneously Installer-friendly Settings shown on the heat pump’s display Compatible with heat pumps in the NIBE F1145/F1245 and F1155/F1255 series. FEATURES OF NIBE PCM 40/PCM 42 The NIBE PCM accessory gives your installation a high degree of flexibility. It is compatible with the NIBE F1145/F1245 and F1155/F1255 series, which was developed in such a way as to enable all the heat pump’s potential applications - both free cooling and hot water production. Combine your heat pump with NIBE PCM for passive / free cooling. It works, even while your system is continually heating hot water. NIBE PCM is easily controlled via the heat pump’s control panel, where both settings and monitoring are easily handled at the push of a button. This accessory’s timeless design means that it blends in well with your other heat pump equipment.

NIBE NV 10

Level monitor of brine collector circuit.

NIBE SOLAR 40

NIBE SOLAR 40 enables solar heating with your heat pump. With additional solar panels and VPAS you get a complete system.

NIBE SOLAR 42

NIBE SOLAR 42 enables solar heating with your heat pump. With additional solar panels and VPBS you get a complete system.

NIBE ERS 30-400

The NIBE ERS 30-400 is a heat recovery ventilation unit with high temperature efficiency up to 94% and low energy consumption. The heat recovery ventilation unit is used in houses with areas up to approx. 350 m2. The NIBE ERS 30-400 is designed for installation with a NIBE ground source heat pump or a NIBE air/water heat pump for a complete heating and ventilation system. The heat recovery ventilation unit is easily controlled by the heat pump. Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected lifestyle. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time.

NIBE SMS 40

GSM remote control. Settings via the heat pump’s display. Adjustment of operation mode via SMS. SMS notifications upon alarm and e g power failure. Status information via SMS.

NIBE KB 25

Combination valve for filling up the brine. Including insulation. For heat pumps max. 13 kW.

NIBE POOL 40

An accessory that allows pool heating using heat pump. Max 18 kW. The heat pump controls the reversing valve, pool circulation pump and any heating circuit circulation pumps via POOL 40.

NIBE FLM

The NIBE FLM is an exhaust air module with built-in fan, specially designed for combining recycling of mechanical exhaust air with a NIBE ground source heat pump, providing an integrated solution for ventilation, hot water and heating. The NIBE FLM has a high fan capacity and low noise level. Energy is recovered from the ventilation air; even when the heat pump is not in operation, energy is stored in the ground or soil collector and exhaust air energy is thus put to maximum use. Thanks to smart technology, the product gives you control over your energy consumption and will be a key part of your connected lifestyle. The efficient control system automatically adjusts the indoor climate for maximum comfort, and you do nature a favour at the same time.

NIBE OPT 10

NIBE OPT 10 is used to enable connection and control of gas boiler NIBE GBM 10-15

NIBE HR 20

NIBE RTS 40

Room sensor used to obtain a more even indoor temperature. RTS 40 has up to three functions: Show current room temperature in the heat pump's display. Option of changing the room temperature in °C. Makes it possible to change/stabilise the room temperature.

NIBE FLM - Console package

FLM - Console package

NIBE RMU 40

With RMU 40 you can control and monitor your Nibe heat pump from another room in the house.

NIBE AXC 40

Accessory card. AXC 40 is used to enable connection and control of Mixing valve controlled additional heat, Pump for hot water circulation, Groundwater pump

NIBE BAU 40

Wall console BAU 40 for wall mounting.

NIBE FLM S45

The NIBE FLM S45 is an exhaust air module with built-in fan, specially designed for combining recycling of mechanical exhaust air with a NIBE ground source heat pump, providing an integrated solution for ventilation, hot water and heating.

The NIBE FLM S45 has a high fan capacity and low noise level. Energy is recovered from the ventilation air; even when the heat pump is not in operation, energy is stored in the ground or soil collector and exhaust air energy is thus put to maximum use.

The NIBE S Series is a natural part of your connected home. Smart technology adjusts the indoor climate automatically while you’re in complete control from your phone or tablet. Giving maximum comfort and minimum energy consumption, while doing naturea favour at the same time.

NIBE MODBUS 40

A NIBE heat pump can be controlled and monitored by external Modbus equipped equipment.

NIBE HR 10

Auxiliary relay HR 10 is a connection box housing a contactor and a rotary selector switch. It is used to control external 1 to 3-phase loads such as oil burners, immersion heaters and pumps.

NIBE EF 45

Extension frame.

NIBE HTS 40

HTS 40 is an accessory that records humidity and temperature.

NIBE ECS 40

ECS 40 is used when heat pump is installed in houses with up to four different climate systems that require different flow line temperatures, for example, in cases where the house has both a radiator system and an under floor heating system.

NIBE EME 20

Communication and control. EME 20 is used to enable communication and control between the inverter for solarcells and heat pump/indoor module/control module.

NIBE ECS 41

Extra heating circuit (recommended 80-250 m2 floor heating). ECS 41 is used when heat pump is installed in houses with up to four different climate systems that require different flow line temperatures, for example, in cases where the house has both a radiator system and an under floor heating system.

Height (mm)

1500

Depth (mm)

620

Net weight (kg)

153

Product efficiency class room heating, 35 °C

A+++

Product efficiency class room heating, 55 °C

A++

System efficiency class room heating, 55 °C

A++

System efficiency class room heating, 35 °C

A+++

Efficiency class water heating

A

Refrigerant amount, CO2 equivalent (ton)

2,66

Refrigerant amount, R407C (kg)

1,5

Declared tap profile

XXL
